Microcomputer controlled bolt torsion testing system (vertical)

Description
Technical Parameter

This machine is mainly used for torsion test of high-strength bolts to measure axial force and torque.  This machine meets the requirements of GB50205-2001 “Code for Acceptance of Steel Structure Engineering”. The testing system is mainly composed of a main machine, a torsion compression mechanism, a deceleration loading mechanism, a frequency conversion system, a control data acquisition system (including torque and load, torsion angle), a computer and its test software, and other necessary loading supports and accessories.  All test operations can be completed on the testing machine through test software.  The automatic collection, storage, processing and display of test data are realized, and the test results can be output by the printer.

Corresponding parameter set not found, please add it in property template of background

Number

Project name

Specifications, parameters and indicators

1

Maximum test torque (Nm)

2000

2

Maximum test axial force (kN)

500

3

Accurate measurement range of test torque (Nm)

100~2000

4

Effective measurement range of axial force (kN)

20-500

5

Torque tolerance and repeatability error



6

Relative error of repeatability of axial force indication



7

Test speed range (/min)(°/min)

0~1000°

8

Bolt specification



Big hexagon M12、M16、M20、M22、M24、M27、M30,

Twist shear M16、M20、M22、M24

9

Direction

Double-sided

10

Motor power (kW)

1.5

11

Supply voltage (V)

AC 380    50Hz
